CX450EPP-V2 - 450 Flybar Electronic Parts Package V2

CopterX (CX450EPP-V2) 450 Flybar Electronic Parts Package V2 .

MG-D-9257-V2 Specification:

• Wire: 25cm
• Operating Voltage: 4.8v ~ 6v
• Operating Speed: 0.09sec/60° (4.8V) / 0.08sec/60° (6.0V)
• Stall Torque: 2.2kg-cm (4.8V) / 2.4kg-cm (6.0V)
• Pulse width: 1520us
• Working Frequency: 333Hz
• Size: 36 x 15.2 x 29mm
• Weight: 25g

CX-1X1000 Features:

• Micro AVCS heading hold gyro
• Compact design to work most helicopter from 100-600 size
• Aluminum casing for accurate vibration free operation
• User selectable between AVCS or Normal mode
• Easily programmable without the aids of complex setup box
• Fully compatible from analog to narrow band digital servo (1.52ms analog, 1.52ms digital, 760us, 960us)
• Compatible with most popular PPM, PCM, 2.4G radio system
• Wide operation voltage from 3.5V to 10V DC

CX-1X1000 Specification:

• Weight: 11g (metal case, cables and plugs included)
• Operating Voltage: DC3.5V - 10V
• Operating Current Drain: 60ma
• Operating Temperature: -10°C - 50°C
• Maximal Angular Velocity: 800°/sec
• Servo Compatibility: 1.52ms analog servo, 1.52ms digital servo, 760us digital servo, 960us digital servo
• Radio Compatibility: PPM, PCM, 2.4G
• Dimensions: 22.2*22.2*11mm

CX-1X1000 Software

CX-ESC-40A Specification:

• Cont. current: 40A
• Burst current(>10s): 55A
• BEC mode: Linear
• BEC output: 5V / 3A
• BEC output capability: 5 servos (2S Lipo) / 4 servos (3S Lipo)
• Battery cell: 2-3S (Lipo) / 5-9 cells (NiMH)
• Weight: 39g
• Dimension: 68*25*8mm

.

Package Included:

• CopterX (CX-9G) 9G Servo X 3
• Fusonic (MG-D-9257-V2) 9257 25g Metal Gear High Speed Mini Digital Servo X 1
• CopterX (CX-1X1000) Mini Heading-Hold Gyro System X 1
• CopterX (CX-ESC-40A) 40A V2 Brushless Electronic Speed Controller X 1
• CopterX (CX450-10-04) 430XL Brushless Motor (3550KV) X 1
